Reinforcement: Single braid of 304/316 series of stainless steel wire
Application: P.T.F.E hose has an excellent temperature characteristics
both in high and low temperature, Excellent chemical resistance,
non contamination properties, low coefficient of friction and resists
deterioration. Therefore the hose is used generally in applications
where all or one of the above properties is the main criteria in
automotive,chemical,pharamceutical & food processing , plastic & rubber
molding machines.Also for some applications the tube can also be
made conductive to dissipate electro-static charges
Note : Working and burst pressure are at 20°C T emperature
| Item | Dash |
.png) |
.png) |
.png) |
.png) |
.png) |
.png) |
.png) |
|||||
| Code | Size |
WT
|
ID
|
OD
|
WP
|
BP
|
BR/r
|
W
|
|||||
| inch | mm | inch | mm | psi | bar | psi | bar | inch | mm | g/m | |||
| PH370-04 | -4 | 0.75 | 1/4 | 6.60 | 0.410 | 10.40 | 2500 | 175 | 10000 | 700 | 0.80 | 20 | 149 |
| PH370-05 | -5 | 0.75 | 5/16 | 8.18 | 0.490 | 12.40 | 2300 | 160 | 9200 | 640 | 0.80 | 20 | 170 |
| PH370-06 | -6 | 0.75 | 3/8 | 9.65 | 0.540 | 13.70 | 1740 | 120 | 6960 | 480 | 0.80 | 20 | 182 |
| PH370-08 | -8 | 0.75 | 1/2 | 12.83 | 0.725 | 18.40 | 1595 | 110 | 6380 | 440 | 1.00 | 25 | 289 |
| PH370-10 | -10 | 0.80 | 5/8 | 16.00 | 0.827 | 21.00 | 1450 | 100 | 5800 | 400 | 2.00 | 50 | 349 |
| PH370-12 | -12 | 0.90 | 3/4 | 19.18 | 1.020 | 25.90 | 1160 | 80 | 4640 | 320 | 2.60 | 65 | 494 |
| PH370-14 | -14 | 1.00 | 7/8 | 22.23 | 1.170 | 29.70 | 870 | 60 | 3480 | 240 | 3.10 | 80 | 565 |
| PH370-16 | -16 | 1.00 | 1 | 25.53 | 1.331 | 33.80 | 800 | 55 | 3200 | 220 | 3.60 | 90 | 677 |
| PH370-20 | -20 | 1.00 | 1.1/4 | 31.88 | 1.680 | 42.70 | 665 | 45 | 2660 | 180 | 4.40 | 110 | 891 |
| PH370-24 | -24 | 1.00 | 1.1/2 | 38.23 | 1.890 | 48.00 | 510 | 35 | 2040 | 140 | 6.00 | 150 | 959 |
| PH370-32 | -32 | 1.10 | 2 | 50.93 | 2.420 | 61.50 | 365 | 25 | 1460 | 100 | 8.00 | 200 | 1309 |
| PH370-48 | -48 | 1.30 | 3 | 76.00 | 3.504 | 89.00 | 236 | 16 | 945 | 65 | 12.20 | 310 | 1550 |
